Electric cold storage pallet truck
EPT20-20ETC
- Load capacity
- 2,000 kg
- Lift height
- 115 mm
- Battery
- 48 V lead-acid
Overview
An electric cold storage pallet truck with a rated capacity of 2,000 kg, a lift height of 115 mm and a 48 V lead-acid battery.
Specifications
Specifications per EP Equipment. Contact us to confirm availability and configuration for Aruba.
- Load capacity
- 2,000 kg
- Lift height
- 115 mm
- Travel speed, laden/unladen
- 4/4.5 km/h
- Battery
- 48 V lead-acid
Show all specifications Hide specifications
Capacity and lifting
- Load centre distance
- 600 mm
- Load distance, centre of drive axle to fork
- 946 mm
- Lift speed, laden/unladen
- 0.027/0.038 m/s
- Lowering speed, laden/unladen
- 0.059/0.039 m/s
Performance
- Max. gradeability, laden/unladen
- 8/20 %
- Service brake
- Electromagnetic
Battery and drive
- Drive motor rating S2 60 min
- 0.9 kW
- Lift motor rating at S3 15%
- 0.8 kW
- Battery voltage
- 48 V
- Battery nominal capacity K5
- 40 Ah
- Battery type
- Lead Acid
- Battery weight
- 40.8 kg
- Type of drive unit
- AC
Dimensions and weight
- Wheelbase
- 1,301 mm
- Service weight
- 309 kg
- Axle loading, laden front/rear
- 722/1,498 kg
- Axle loading, unladen front/rear
- 180/40 kg
- Tread width, rear
- 410 (535) mm
- Overall length
- 1,673 mm
- Length to face of forks
- 522 mm
- Overall width
- 560 (685) mm
- Fork dimensions
- 50/150/1,150 mm
- Ground clearance, centre of wheelbase
- 30 mm
- Aisle width for pallets 1000×1200 crossways
- 2,307 mm
- Aisle width for pallets 800 × 1200 lengthways
- 2,179 mm
Wheels and tyres
- Tyres
- Rubber/Polyurethane, Rubber/Nylon
- Tyre size, front
- Φ210 × 70mm
- Tyre size, rear
- Φ80 × 61 / 105 × 88mm
- Additional wheels (castor wheels)
- —mm
- Wheels, number front/rear (x=drive wheels)
- 1x, -/4
General
- Drive
- Electric
- Operator type
- Pedestrian
- Steering design
- Mechanical
- Sound pressure level at the driver's seat
- 74 dB(A)
