Standing electric deep reach truck
CQD15SD
- Load capacity
- 1,500 kg
- Lift heightUp to 11,500 mm with optional mast
- 8,500 mm
- Battery
- 48 V Li-ion
Overview
A standing electric deep reach truck with a rated capacity of 1,500 kg, a lift height of 8,500 mm (up to 11,500 mm with optional mast) and a 48 V Li-ion battery.
Specifications
Specifications per EP Equipment. Contact us to confirm availability and configuration for Aruba.
- Load capacity
- 1,500 kg
- Lift height (standard mast)
- 8,500 mm
- Max. lift height
- 11,500 mm with optional mast
- Travel speed, laden/unladen
- 11/12 km/h
- Battery
- 48 V Li-ion
- Turning radius
- 1,945 mm
Show all specifications Hide specifications
Capacity and lifting
- Load centre distance
- 600 mm
- Load distance, centre of drive axle to fork
- 215 mm
- Tilt of mast/fork carriage forward/backward
- 2/5 °
- Height, mast lowered
- 3,660 mm
- Free lift
- 2,610 mm
- Height, mast extended
- 9,540 mm
- Fork carriage ISO 2328, class/type A, B
- 2A
- Fork carriage width
- 800 mm
- Lift speed, laden/unladen
- 0.45/0.5 m/s
- Lowering speed, laden/unladen
- 0.5/0.5 m/s
Performance
- Max. gradeability, laden/unladen
- 10/12 %
- Service brake
- Electromagnetic
- Parking brake
- Electromagnetic
Battery and drive
- Drive motor rating S2 60 min
- 7 kW
- Lift motor rating at S3 15%
- 20 kW
- Battery voltage
- 48 V
- Battery nominal capacity K5
- 600 Ah
- Battery type
- Lead Acid/Li-ion
- Battery weight
- 900 kg
- Type of drive unit
- AC
- Charger output current
- 80 A
Dimensions and weight
- Wheelbase
- 1,700 mm
- Service weight
- 4,390 kg
- Axle loading, laden front/rear
- 2,297/3,593 kg
- Axle loading, unladen front/rear
- 2,590/1,800 kg
- Tread width, front
- 721.5 mm
- Tread width, rear
- 1,006 mm
- Height of overhead guard (cabin)
- 2,330 mm
- Seat height relating to SIP/stand height
- 250 mm
- Height of wheel arms
- 130mm
- Overall length
- 2,790 mm
- Length to face of forks
- 1,717 mm
- Overall width
- 1,078/1,148 mm
- Fork dimensions
- 40/100/1,070 mm
- Ground clearance, laden, below mast
- 45 mm
- Ground clearance, centre of wheelbase
- 50 mm
- Aisle width for pallets 1000×1200 crossways
- 3,125 mm
- Aisle width for pallets 800 × 1200 lengthways
- 3,195 mm
Wheels and tyres
- Tyres
- Polyurethane
- Tyre size, front
- Φ343 × 40mm
- Tyre size, rear
- Φ127 × 98mm
- Additional wheels (castor wheels)
- Φ178 × 73mm
- Wheels, number front/rear (x=drive wheels)
- 1 × 2/4
- Distance between wheel arms/loading surfaces
- 864
General
- Drive
- Electric
- Operator type
- Standing
- Distance between fork-arms
- 250/780 mm
- Steering design
- Electronic
- Sound pressure level at the driver's seat
- 75 dB(A)
